High Performance SVC Control Mode

With advanced sensorless vector control technology, our FR600 Series SVC inverter delivers outstanding performance in precision, responsiveness, and torque output.

Speed Control Accuracy; +0.5%

Speed Control Range : 1:100

Torque Control Response time: <200ms

Starting Torque: 180% Rated Torque/0.5Hz

• Excellent Master-Slave Control

Thevector control inverter is designed for multi-motor systems, which ensures power balance across all connected motors, reducing wear and extending service life.

•Rich Autotuning Function

The medium voltage variable frequency drive inverter supports both rotary and static autotuning. It shortens commissioning time and optimizes the drive performance.

Rotary Autotuning

Static Autotuning

•Multi I/O Interface

As a vector control inverter, FR600 provides a comprehensive set of I/O interfaces to support various system integrations.

7 channels programmable digital input, one of them supports high speed pulse input.

3 channels analog input, two of them support 0-10V or 0-20mA choice, one of them support-10V~+10V.

2 channels programmable relay output.

2 channels programmable collector output.

2 channels programmable analog output.

1 channel support MODBUS-RTU standard RS-485 interface.

1 channel 24V power, maximum output current: 200mA.

1 channel 10V power, max output 10mA.

• Multi-protection

As a reliable 3 phase variable frequency drive inverter designed for industrial environments, it integrates multiple protection features to ensure safe and stable operation, including built-in Motor protection, over current protection, over voltage protection, over temperature protection, ground protection and so on.

• Large Margin Derating Design

This vector control inverter uses a high-performance 32-bit Cortex-M3 ARM processor and Infineon 1700V IGBT modules. Key components, such as capacitors and rectifiers, have a large margin of derating in their design, which makes the device more reliable and durable across various voltage systems.

•Abundant Function

The three phase voltage source inverter integrates G&P in one unit, supports PID control for fans and pumps without extra devices, solving user challenges like complex control, energy waste, and unstable motor starts. It adapts to different motors and features dormant/wakeup and smooth speed tracing functions, helping save energy and adapt to different sites.

•Integrated Model with G&P in One

This 3 phase variable frequency drive inverter is designed for fan and pump applications, with built-in PID control for temperature, pressure, and flow. It enables efficient regulation without the need for additional controllers and helps conserve energy based on air or water flow. Different motor characteristics result in different effects.

•Dormant & Wakeup Function

The inverter supports frequency-dormant and wakeup, as well as pressure-dormant and wakeup, delivering better adaptability for various sites.

•Speed Tracing Function

The Inverter starts the motor smoothly according to the motor's current running direction and speed.
