General Purpose Inverter

FR30 Series High Performance Inverter

The FR30 series is one of the best variable frequency drive inverters from FRECON, boasting high performance, high quality, and high power density design. The industrial inverter is mainly positioned as a full-featured product in the mid-to-high-end market. Its design is flexible, featuring built-in VC, SVC, and VF controls. This high performance inverter can be widely used in applications with high requirements for speed control accuracy, torque response speed, and low-frequency output characteristics.


Get a Quote Data Download

Feature Specification Application Download

 STO(Safe Torque Off) Standard Built-in

This STO inverter stops torque transmission immediately in hazardous situations, preventing accidental motor start and ensuring compliance with industrial safety standards.

 Excellent Performance

As a high performance inverter, it delivers precise motor control, stable output, and efficient operation across a wide range of industrial environments.

 Flexible and Diverse Terminal Functions

The FR 30 series offers versatile terminal configurations for flexible system integration, making it one of the best variable frequency drive options for customized industrial setups.

 Reactor and EMC

Harmonic reduction with dual DC reactors meets the EN61000-3-12 harmonic standard. Integrated EMC C2 filters enables this AC inverter to be installed in complex environment.

 CE Certification

All the FR 30 series inverters comply with CE certification standards, meeting stringent European safety, environmental, and performance requirements.

 Built-in adaptive PID Function Module

As a PID inverter, it supports sleep/wake functions triggered by frequency or pressure, multiple feedback source selections, and dual PID parameter sets that switch automatically based on load or deviation. This enhances precision control in closed loop inverter systems.

 Reliability Design

The high performance inverter operates reliably even when V/F control is fully separated or semi-detached. It can automatically perform current compensation under heavy loads to maintain a constant output voltage.

 Operate When the V/F is Fully Separated and Semi-detached

The FR30 series can automatically compensate for current under heavy loads to maintain a constant output voltage, meeting the application requirements of the power supply industry.

 Speed Tracking Function

In cases where rapid start-up is required, the variable frequency drive VFD inverter can achieve a smooth and non-impact start of the motor according to the current running direction and rotational speed of the motor.

 Communication and Encoder Card Support

The industrial inverter is compatible with various communication expansion cards and encoder cards, ensuring flexible integration into industrial automation systems.

 Convenient Debugging

Equipped with powerful background software, this high performance inverter offers a dedicated upload/download module for quick parameter setup, backup, and troubleshooting. It develops dedicated application macros based on industry needs.

 Diversified IP Level Design

This industrial inverter features robust IP-rated protection to safeguard against dust, moisture, and other environmental hazards, ensuring reliable operation even in the most demanding industrial settings.

 Oscillation Suppression Function

When the motor oscillation is detected, the output voltage is automatically fine-tuned. The frequency enables the motor to run smoothly. FR 30 is considered among the best variable frequency drives for stability and performance.



Applications

As one of the world’s well-known variable frequency drive suppliers, FRECON offers a wide range of variable frequency drive VFD inverter, from 1 hp variable frequency drive models to heavy-duty 150 hp solutions, meeting the needs of diverse industries. FR30 inverters are suitable for fans, water pumps, conveyors, compressors, and OEM machinery that requires accurate control.
