Solar Pump Inverter

PV150A Series Solar Pumping Drive

PV150A series is an advanced MPPT water pump inverter of FRECON Solar PV Inverter. PV150A series features a hybrid supply, built-in protection, advanced MPPT algorithms, no battery operation, and a larger water yield. It applies to AM, PMSM, BLDC, etc.

Get a Quote Data Download

Feature Specification Application Download


Applicable to AM, PMSM, BLDC, etc.

Advanced MPPT Algorithms

Efficiency reaches 99%

Hybrid Power Supply

Support DC solar power / AC grid power input at same time.

And DC/AC auto switch.

Dormancy and Wake-up function Inverter will enter dormancy mode

Inverter will enter dormancy mode and wake up automatically according to the sunshine intensity

Built-in Protection

Support over-current, over-voltage, phase loss,

shortcircuit, over-temperature protection etc.


Operation without battery

Large Water Yield

Larger water yield under the same condition

Water Level Control

Dry run protection, tank water level control

Recording Functions

Recording for total power generated (Kw/h),

waterflow(m3), and operation time(H)

Understand the power of the PV150A series MPPT inverter through professional eyes. Download our product detail pdf and view more specific data and specs about the PV150A.
